Beijing Silk Road Enterprise Management Services Co.,LTD
6 Years
| Ask Lasest Price | |
| Brand Name : | |
| Model Number : | |
| Certification : | CE, CCC, FCC, ROSH, ISO9001 |
| Price : | USD 400-1999 per sqm |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 1300 square meters per month |
| Delivery Time : | within 15 to 20 working days after receiving deposit |
Quick Assembly P6 Foldable Led Screen Portable Led Display Indoor
The training class is mainly to assure customer have good used the products. It needs both of the buyer and seller to work along with the contract. Seller is responsible for training buyers how to operate the software of LED screen and some basic hardware mantenance knowledge. When installing and testing are being well-finished, the detailed training class informations as below:
1. The basic operation principal
2. Procedures and managements of system operation
3.The daily maintenance and safety caution
4. System software installation
5. Simple software failure treatment
6. Simple hardware failure treatment
Specifications:
| Pixel Pitch | 6.25mm |
| Pixel Package | SMD3535 |
| LED Configuration | 1R1G1B |
| Pixel Density | 25600 Pixels/㎡ |
| Module Size | 250mm x 250mm |
| Module Resolution | 40 x 40 dots |
| Suggested Cabinet Size | 500mm x 1000mm x 75mm |
| Cabinet Resolution | 80 x 160 dots |
| Cabinet Material | Die-casting Aluminum Alloy |
| Cabinet Weight | 9.6 kg/panel |
| Brightness | 4000-6000 nits |
| Color Temperature | 3000-12000K |
| Viewing Angle | H-140°/ V-140° |
| Driving Mode | 1/5 |
| Refresh Rate | 1920-3840Hz |
| Frame Frenquency | 60Hz |
| Grey Level | 4096-16384 |
| Number of Color | 1 billion |
| Input Maximum Power | 500 W/㎡ |
| Input Voltage | AC220±10%, AC110 ±10% |
| Input Frequency | 50-60Hz |
| External Interface | S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc |
| IP Rating | IP65 |
Features:
1. seamless assembling, less than 1mm.
2. High-definition visual effect.
3. High thermal conductivity Alloy cabinet, better heat dissipation
4. Fan-free design, energy saving, more stable,
5. 140〫 degree wilde view angle
6. Power, signal indicators in the power box.
7. Approved by RoHS certification, Lead-free, enviromental design
8. Ergonomic handle design, convenient handling
9. High performance and adjustable side lock.
10. International standards air plug on Power connectors, easy, fast and safe.
11. Receiving card to card with LAN cable, simple, less failure rate
|
|
